Healthcare
At Quam, we believe that once installed, a loudspeaker shouldn’t need maintenance, repair or replacement. Property owners and installers should expect loudspeaker installations to outlast the building. Our Healthcare Solutions consistently exceed expectations with ‘Right-out-of-the-box’ reliability and unmatched durability that comes from more than 80 years of hands-on, continuous product improvement.
Make Quam your source for the best built Healthcare Solutions in America:
- All of our speakers are designed to be ascetically pleasing
- Many of our solutions are enhanced for greater voice intelligibility and performance
- We offer a wide array of UL listed solutions that comply with MNS and fire codes
- All of our solutions are built to minimize installation and labor costs
Product Spotlight
SYSTEM 5 Series
|
The SYSTEM 5 is a complete, UL Listed, shallow depth, lightweight, 1' x 2' ceiling tile replacement loudspeaker system consisting of an 8C5PAX - 8" O.D. dual cone loudspeaker with a 5 oz. magnet and a TBLU - 5W-25/70V transformer. Molded fiber enclosure is 617 CID. Steel baffle with standard perforation and four (4) seismic tie-off points. Cable clamp and one (1) 24" "T" rail for finishing the edge are included. No assembly required. Order Here |
SYSTEM 12 Series
|
The SYSTEM 12 is a complete, UL Listed, shallow depth, lightweight, 2' x 2' ceiling tile replacement loudspeaker system consisting of an 8C5PAX - 8" O.D. dual cone loudspeaker with a 5 oz. magnet and a TBLU - 5W-25/70V transformer. Molded fiber enclosure is 1,412 CID. Steel baffle with standard perforation and four (4) seismic tie-off points. Cable clamp is included. No assembly required. Order Here
|
SYSTEM 19 Series
|
The SYSTEM 19 is a complete, UL Listed, 2-way, shallow depth, lightweight, 2' x 2' ceiling tile replacement loudspeaker system consisting of an 6-1/2" O.D. LF woofer, 1" tweeter, and a 20W-70V rotary select transformer including an 8 Ohm tap. Molded fiber enclosure is 1412 CID. Steel baffle with standard perforation and four (4) seismic tie-off points. Cable clamp is included. No assembly required. Order Here
|
UL22 Series
|
The UL22/25 is a complete UL Listed (UL 1480-F and UL 2043), shallow depth, lightweight, tile replacement, fire-protective signaling device with an 8C10PAFR - 8” O.D. loudspeaker, 10 oz. magnet, fire retardant components and a 4W-25V rotary select transformer. Integral enclosure is 1,412 CID molded fiber. Grille is perforated steel with five (5) seismic tie-off points in a white powder coat finish. Line supervision capacitor is included. No assembly required. Order Here
|
SOLUTION 1
|
The SOLUTION 1 is a complete speaker/transformer/baffle solution for ceiling installations. Each installer package includes two (2) C10X/BU/WS - The 8C10PAX - 8Ω O.D. dual cone loudspeaker with a 10 oz. magnet and a TBLU - 5W-25/70V transformer mounted on a BR8WS - round, steel, stud mount baffle. Also included are two (2) SSB-3 - rust-resistant steel, load bearing supports and two (2) ERD8U - 275 CID, round, steel back boxes. Order Here
|
SOLUTION 3
|
The SOLUTION 3 is a complete speaker/transformer/designer baffle solution for ceiling installations. Each package includes two (2) C10FX/BU/2WS - The 8C10FEPAX - 8Ω O.D. foam edge surround, dual cone loudspeaker with a 10 oz. magnet and a TBLU - 5W-25/70V transformer mounted on a BR8-2WS - designer baffle. Also included are two (2) SSB-6 - rust-resistant steel, load bearing supports and two (2) ERD8U - 275 CID, round, steel back boxes. Order Here |
WS20x16
|
The WS20X16 is a 20"W x 16"D wall mount equipment shelf with a ventilated platform, 1/2" raised front lip, two support arms, and a maximum static load capacity of 100 lbs. Black powder coat finish. No Assembly required. Order Here
|
BB2 Series
|
The BB2 is a complete, beam mount loudspeaker system consisting of an 8C10PAX - 8" O.D. dual cone loudspeaker with a 10 oz. magnet, TBLU - 5W-25/70V transformer, BR8WS - round, studded baffle and two (2) beam clamps attached to a round, steel backbox. Order Here |
FM4X1/70/W
|
The FM4X1/70/W is a complete 2-way loudspeaker with a 4' O.D. Woofer, 3/4" dome tweeter, 20W-70V low loss, extended frequency response rotary select transformaer with an 8 Ohm position in a white finish. Multiple position "U" bracket included. Order Here
|
QH16T
|
The QH16T is a double re-entrant horn, compression type loudspeaker with an integrated 16W-25/70V rotary select transformer and an adjustable mounting base. Order Here
|
MA/E8/S2/T8
|
The MA/E8/S2/T8 is a 690 CID sound masking loudspeaker assembly consisting of an 8C10PAX-8" O.D. dual cone loudspeaker with a 10 oz. magnet, and a 4W-70V rotary select transformer. 4' suspension chain is supplied. Order Here
|
